SHIMANO Spinning Reel 26 STELLA SW 6000HG JAPANSHOPTOKYO
About this product
- Gear ratio: 5.7 / Maximum drag force (kg): 13.0
- Weight (g): 440 / Spool diameter/stroke (mm): 58/19
- Line capacity nylon (no.-m): 4-240, 5-190, 6-160 / Line capacity PE (no.-m): 2-440, 3-300, 4-210
- Maximum retrieval (cm/handle rotation): 104 / Handle length (mm): 70
- Number of bearings (BB/roller): 12/1
XX TOUGH DRAG
【Evolution of drag durability】
Each drag part that absorbs intense runs now features carbon washers exclusive to the Stella SW, which are metal-based and highly resistant to wear. In addition to the drag washers conventionally located at the bottom, the spool structure has been evolved to include them at the top, allowing for the installation of large washers with approximately four times the surface area of the previous model.
This evolution improves drag durability.
The synergistic effect of the improved drag structure and the equipped Heat Sink Drag has also successfully reduced the drop in drag force due to heat by approximately 30% compared to previous models.
Overwhelming stopping power that forcefully controls the catch while absorbing the fish's pull and tracking it smoothly, combined with unwavering durability. This drag, which fuses softness and rigidity, is the proof of the Stella SW's existence.
INFINITYLOOP
【Oscillation system thoroughly thought out exclusively for SW】
Infinity Loop improves casting distance, casting feel, and drag smoothness by winding the line neatly and precisely. Meticulously designed mechanisms, such as the optimal line-winding pitch for SW models, improvements in the line-winding shape as the line is taken onto the spool, and a 2-speed oscillation system that changes pitch during spool reciprocation, bring further improvements to line release performance and trouble-free operation. This benefit translates directly not only to a steady casting feel and increased distance, but also to smooth line release in vertical jigging. Even under high-load conditions such as complex currents or heavy-weight jigs, it prevents line digging and snagging, allowing metal jigs to reach the target depth quickly. Furthermore, after a hit, it maintains a stable drag force with minimal fluctuation in line tension to suppress the intense pulls of a monster.
AR-C Spool
The AR-C spool, with its specially shaped spool ring, creates a rectifying effect for the line, contributing to the suppression of line trouble and improved long-distance casting performance. The 25 Stella SW is equipped with a new AR-C design that features a spool ring color shaped to prevent the line from climbing over, reducing the line straddling on the spool that causes line trouble.
Also, in SW games, the spool ring is subjected to unexpected loads under harsh conditions. The surface of the spool ring is treated with a powerful, wear-resistant barrier coat to further improve durability. This also reduces damage to the line, keeping the surface smooth and resistant to scratches for longer.
INFINITYXROSS
【The heart of the SW, improved gear strength and durability】
Infinity Xross expands the contact surface area where the drive gear and pinion gear mesh through advancements in the design and manufacturing technology of gear tooth surfaces. By distributing the load on the gear tooth surfaces, it prevents damage caused by the concentration of stress and improves durability. The 25 Stella SW has increased this tooth width by approximately 1.3 times compared to the previous model. It is now possible to maintain a smooth gear feeling even during high-load retrieval.
ANTI-TWIST FIN
A fin is installed near the line roller to suppress line slack, reducing line drop onto the spool skirt. The fin uses an elastic material to prevent damage when winding in knots.
Fin B, which creates a gap as in the past, is also included.
Further improved operability with a newly designed drag knob
The Stella SW, with its refined details, features a drag knob with an approximately 25% larger diameter to further enhance operability (*). This not only makes it easier to grip the knob during instantaneous operation, but also makes it easier to perform fine adjustments. It provides an advantage when tightening or loosening the drag in an instant when a big fish is hooked.
*For 8000 size and above
X PROTECT & X SHIELD
A threat in SW games is the intrusion of seawater. Seawater that enters the reel corrodes metal parts and significantly degrades initial performance.
The Stella SW uses seals in various places, including the body, drag knob, and line roller, to block water intrusion paths. In particular, the body and stopper sections have achieved IPX8, a standard for waterproof performance. This brings high reliability and durability to SW games played under harsh conditions.
In addition, by reviewing the waterproof structure, we have achieved even lighter rotational performance while maintaining waterproof capability. It achieves the conflicting elements of high waterproof performance and silky rotation.
X Rigid Handle
A high-rigidity cold-forged handle exclusive to the Stella SW that transfers the angler's power without loss.
